GRIP! M

NEW

Color

Colour temperature

Select the item now with matching

25+ in Stock

Art. no.: 1012376

Delivery information

Delivery time: 1–3 working days

Technical overview

42 °
50000 h
IP20
IK02

DALI dimming: This product is dimmable using a DALI dimmer.
Gimballed: This product can be swivelled and pivoted.
Direct lighting - beam angle: This value describes the beam angle in degrees. The smaller the angle, the more concentrated the light will be.
Average lifespan in h: The average lifespan of a lightbulb or light source in hours.
IP protection rating: The IP protection class indicates the suitability of electrical equipment for different environmental conditions.
IK impact resistance rating: The IK impact resistance rating is a measure of the resistance of the housing of electrical equipment to mechanical stress, especially impact stress.

Technical data

Product name: GRIP! M
EAN Number: 4024163343305
Colour: white/black
Assembly: Track
Luminous Flux: 1540 lm
Colour temperature: 3000 Kelvin
CRI: 90
Half beam angle: 42 °
Different light outlets: 1
Length: 22.6 cm
Width: 4.3 cm
Height: 8.8 cm
Shape: cylindrical
Material: Aluminum
IP Code: IP20
Shock resistance category: IK02

Shock resistance: 0.2 joule
Vertical tilting range: 90 °
Horizontal rotation range: 340 °
Assembly details: Ceiling
electrical power: 13 W
Primary nominal voltage: 48V DC
Secondary power / secondary voltage: 350 mA
Dimmable: Yes
Dimming technology: DALI 2
Weighted consumption: 13 kWh/1.000h
Service life: 50000 h
Energy efficiency class: LS_10160
Ambient temperature: 35 °C
Risk group: 1
Net weight: 0.21 kg
BIG WHITE Page: 465

Product information

The GRIP! M 48V Spot is a recessed spot luminaire for the ceiling track system, distinguished by its deep and flush-mounted design. It is particularly suitable for indoor use where precise and glare-free lighting is required. The luminaire delivers a luminous flux of 1540 lumens at 13 watts with a colour temperature of 3000 Kelvin, producing warm white light. The beam angle is 42 degrees, allowing for targeted light distribution. The housing is made of aluminium and measures 22.6 cm in length, 4.3 cm in width, and 8.8 cm in height. The luminaire features a DALI-2 dimming function and offers impact resistance of IK class 02 as well as an ingress protection rating of IP20.
