OVANA 30

NEW

Color

RRP€234.00Price for trade customers only, excl. VAT & shipping

Available as of 02/11/2026

Art. no.: 1011994

Delivery information

Delivery time: 1–3 working days

Technical overview

105 °
50000 h
IP20
22

Leading and trailing edge phase dimmer: This product is dimmable using a trailing and leading edge phase dimmer.
Direct lighting - beam angle: This value describes the beam angle in degrees. The smaller the angle, the more concentrated the light will be.
Average lifespan in h: The average lifespan of a lightbulb or light source in hours.
IP protection rating: The IP protection class indicates the suitability of electrical equipment for different environmental conditions.
UGR ≤: UGR= Unified Glare Rating. Indicates the standardised value of psychological glare. The smaller the value is, the lower the glare.
CCT switch: By using the CCT switch integrated in this product, the light colour can be configured at installation to 3000K or 4000K.

Technical data

Product name: OVANA 30
EAN Number: 4024163339254
Colour: white
Assembly: Surface
Luminous Flux: 1200/1320/1330 lm
Colour temperature: 2700/3000/4000 Kelvin
CRI: 90
Half beam angle: 105 °
UGR ≤: 22
CCT Switch: Yes
Different light outlets: 1
Height: 12 cm
Diameter: 30 cm
Shape: round
Material: Steel
IP Code: IP20
Assembly details: Ceiling
electrical power: 11 W

Primary nominal voltage: 220-240V V ~ 50/60Hz
Secondary power / secondary voltage: 250
Dimmable: Yes
Dimming technology: Leading edge, trailing edge
Inrush current level: 5 A
Inrush current duration: 300 µs
Number of lights on LS B16A: 56
Number of lights on LS C16A: 118
Weighted consumption: 11 kWh/1.000h
Service life: 50000 h
Energy efficiency class: LS_10490
Ambient temperature: 40 °C
TC point (°C): 85 °C
Risk group: 1
Net weight: 1.7 kg

Product information

The OVANA 30 surface-mounted ceiling light is designed for indoor use and is particularly suitable for general lighting in residential and work areas. It features an LED light source with a luminous flux of 1200 to 1330 lumens and a rated lifetime of 50,000 hours. The housing is made of steel and polycarbonate, ensuring a robust and durable construction. With a diameter of 30 cm and a height of 12 cm, the luminaire is compactly designed. Dimming is possible via leading-edge and trailing-edge phase control, allowing flexible light adjustment. The IP20 protection rating indicates that the luminaire is suitable for dust-protected indoor environments without direct exposure to moisture.

Downloads

Product information

Datasheet (PDF)

Manual (PDF)

Maßzeichnung (JPG)

Documents

CE Declaration (PDF)

REACH (PDF)

Tender data

Tender Text (TXT)

GAEB file (D81)
