SURFACE V 390

250+ in Stock

Art. no.: 1007517

Delivery information

Delivery time: 1–3 working days

Technical overview

120
50000 h
IP44
IK02

Direct lighting - beam angle: This value describes the beam angle in degrees. The smaller the angle, the more concentrated the light will be.
Average lifespan in h: The average lifespan of a lightbulb or light source in hours.
IP protection rating: The IP protection class indicates the suitability of electrical equipment for different environmental conditions.
IK impact resistance rating: The IK impact resistance rating is a measure of the resistance of the housing of electrical equipment to mechanical stress, especially impact stress.
CCT switch: By using the CCT switch integrated in this product, the light colour can be configured at installation to 3000K or 4000K.

Technical data

Product name: SURFACE V 390
EAN Number: 4024163278492
Colour: white
Luminous Flux: 1850/2000 lm
Colour temperature: 3000/4000 Kelvin
CRI: 80
Half beam angle: 120 °
CCT Switch: Yes
Height: 11.5 cm
Diameter: 39 cm
Material: Steel
IP Code: IP44
Shock resistance category: IK02
electrical power: 20 W

Primary nominal voltage: 220-240V V ~ 50/60Hz
Secondary power / secondary voltage: 165/120/84mA
Inrush current level: 25.4 A
Inrush current duration: 200 µs
Number of lights on LS B16A: 13
Number of lights on LS C16A: 22
Weighted consumption: 20 kWh/1.000h
Service life: 50000 h
Energy efficiency class: LS_2837
Ambient temperature: 40 °C
Net weight: 0.771 kg

Product information

Discover our new technical product range: SLVtec.With state-of-the-art LED technology, we offer energy-efficient and functional lighting solutions for indoor and outdoor use. From wet room lights to high-bay spotlights – our high-quality products impress with functionality and a fair price-performance ratio. These include the high-quality designed SURFACE V wall-mounted light, which is optionally available with a motion sensor. The light colour (3000 K/4000 K) and light intensity (1850 lm/200 lm) can be easily adjusted via dip switches. With a large beam angle of 120°, it homogeneously illuminates any environment, and its service life of 50,000 hours makes it ideal for long-term use. And the removable cover also makes installation easy. Decide in favour of SLVtec today.

Downloads

Product information

Datasheet (PDF)

Manual (PDF)

Removal instructions (PDF)

Mounting Dimensions Drawing (PDF)

Maßzeichnung (JPG)

Documents

CE Declaration (PDF)

REACH (PDF)

Tender data

Tender Text (TXT)

GAEB file (D81)

Lighting planning data

Download ROLF Zip file (ZIP)

Download ULD file (ULD)
