NEW TRIA®

Colour temperature

Select the item now with matching

RRP€95.00Prices for business customers excl. VAT

25+ in Stock

Art. no.: 1007411

Optionally available

Delivery information

Delivery time: 1–3 working days

Technical overview

60 °
50000 h
IP20

Leading and trailing edge phase dimmer: This product is dimmable using a trailing and leading edge phase dimmer.
Direct lighting - beam angle: This value describes the beam angle in degrees. The smaller the angle, the more concentrated the light will be.
Average lifespan in h: The average lifespan of a lightbulb or light source in hours.
IP protection rating: The IP protection class indicates the suitability of electrical equipment for different environmental conditions.

Technical data

Product name: NEW TRIA®
EAN Number: 4024163277563
Colour: white
Luminous Flux: 1130 lm
Colour temperature: 2700 Kelvin
CRI: 90
Half beam angle: 60 °
CCT Switch: No
Height: 5 cm
Diameter: 7 cm
Material: Aluminium
IP Code: IP20
electrical power: 13,3 W
Primary nominal voltage: 220-240V V ~ 50/60Hz

Secondary power / secondary voltage: 350 mA
Dimmable: Yes
Dimming technology: Leading edge, trailing edge
Inrush current level: 2 A
Inrush current duration: 80 µs
Number of lights on LS B16A: 85
Number of lights on LS C16A: 144
Weighted consumption: 14 kWh/1.000h
Service life: 50000 h
Energy efficiency class: LS_2880
Ambient temperature: 35 °C
Risk group: 1
Net weight: 0.228 kg
BIG WHITE Page: 85

Product information

Discover the new generation of our NEW TRIA® recessed ceiling light and configure an individual lighting experience. The 12 W LED MODULE is a modular element and fits the New Tria 95 recessed rings and is available with different light colours (2700 K/3000 K) and beam angles (38°/60°) as a phase variant. The robust design and excellent colour reproduction index CRI >90 make this an exceptional quality product. In addition, the NEW TRIA® LED MODULE is impressive because of its service life of L80B10@50,000h.

Downloads

Product information

Datasheet (PDF)

Manual (PDF)

Removal instructions (PDF)

Maßzeichnung (JPG)

Documents

CE Declaration (PDF)

REACH (PDF)

Tender data

Tender Text (TXT)

GAEB file (D81)

Lighting planning data

Download ROLF Zip file (ZIP)
