HIGHBAY V 330

NEW

Select the item now with matching

RRP£202.00Prices for business customers excl. VAT

250+ in Stock

Art. no.: 1007679

Delivery information

Delivery time: 1–3 working days

Technical overview

90
50000 h
IP65
IK08

Direct lighting - beam angle: This value describes the beam angle in degrees. The smaller the angle, the more concentrated the light will be.
Average lifespan in h: The average lifespan of a lightbulb or light source in hours.
IP protection rating: The IP protection class indicates the suitability of electrical equipment for different environmental conditions.
IK impact resistance rating: The IK impact resistance rating is a measure of the resistance of the housing of electrical equipment to mechanical stress, especially impact stress.

Technical data

Product name: HB 330
EAN Number: 4024163288125
Colour: black
Luminous Flux: 32000 lm
Colour temperature: 4000 Kelvin
CRI: 80
Beam angle: 90 °
CCT switch: No
Height: 11.9 cm
Diameter: 33 cm
IP Code: IP65
Shock resistance category: IK08
Shock resistance: 5 joule
electrical power: 200 W

Primary nominal voltage: 220-240V V ~ 50/60Hz
Secondary power / secondary voltage: 830 mA
Connection cable length: 150 cm
Inrush current level: 65 A
Inrush current duration: 113 µs
Number of lights on LS B16A: 14
Number of lights on LS C16A: 24
Weighted consumption: 200 kWh/1.000h
Service life: 50000 h
Energy efficiency class: LS_2917
Ambient temperature: 40 °C
Glass temperature (light emission): 65 °C
Risk group: 0
Net weight: 2.324 kg

Product information

Discover our new technical product range: SLVtec. With state-of-the-art LED technology, we offer energy-efficient and functional lighting solutions for indoor and outdoor use. From wet room lights to high-bay spotlights – our high-quality products impress with functionality and a fair price-performance ratio. This includes the HIGHBAY V pendant light, whose light intensity can be adjusted up to 32000 lm via dip switches. With its protection code IP65, it is optimally protected against dirt and moisture. At the same time, it impresses with its modern design and a service life of L70/B50@50,000h. Decide in favour of SLVtec today.

Downloads

Product information

Datasheet (PDF)

Manual (PDF)

Maßzeichnung (JPG)

Documents

CE declaration (PDF)

REACH (PDF)

Tender data

Tender Text (TXT)

GAEB file (D81)

Lighting planning data

Download Rolf Zip file (ZIP)

Download ULD file (ULD)
