NEW TRIA® UNIVERSAL

Select the item now with matching

RRP£66.00Price for trade customers only, excl. VAT & shipping

100+ in Stock

Art. no.: 1007431

Optionally available

Delivery information

Delivery time: 1–3 working days

Technical overview

38
50000 h
IP20

Leading and trailing edge phase dimmer: This product is dimmable using a trailing and leading edge phase dimmer.
Direct lighting - beam angle: This value describes the beam angle in degrees. The smaller the angle, the more concentrated the light will be.
Average lifespan in h: The average lifespan of a lightbulb or light source in hours.
IP protection rating: The IP protection class indicates the suitability of electrical equipment for different environmental conditions.
CCT switch: By using the CCT switch integrated in this product, the light colour can be configured at installation to 3000K or 4000K.

Technical data

Product name: NEW TRIA® UNIVERSAL
EAN Number: 4024163277365
Colour: black
Luminous Flux: 540/600/600 lm
Colour temperature: 2500/3000/4000 Kelvin
CRI: 90
Beam angle: 38 °
CCT switch: Yes
Height: 3.3 cm
Diameter: 5 cm
Material: Aluminium
IP Code: IP20
electrical power: 8,6 W
Primary nominal voltage: 220-240V V ~ 50/60Hz

Secondary power / secondary voltage: 100-180mA
Dimmable: Yes
Dimming technology: Leading edge, trailing edge
Inrush current level: 10 A
Inrush current duration: 100 µs
Number of lights on LS B16A: 128
Number of lights on LS C16A: 212
Weighted consumption: 9 kWh/1.000h
Service life: 50000 h
Energy efficiency class: LS_2877
Ambient temperature: 35 °C
Risk group: 1
Net weight: 0.153 kg
BIG WHITE Page: 79

Product information

Discover the new generation of our NEW TRIA® recessed ceiling light and configure an individual lighting experience. A modular element is the multi-wattage LED MODULE, which is variably adjustable in terms of output (4.4 W/5.5 W/7.3 W/8.6 W) and light intensity (540 lm/600 lm/600 lm). The CCT switch, which allows easy selection between 2500 K, 3000 K and 4000 K, also provides even more lighting design options. The LED MODULE is available with different beam angles (38°/60°) as a phase variant. The robust design and excellent colour reproduction index CRI >90 ensure exceptional quality. In addition, the NEW TRIA® UNIVERSAL LED MODULE impresses with its service life of L80B10@50,000h.
