NEW TRIA®

Colour temperature

Select the item now with matching

RRP£39.00Prices for business customers excl. VAT

500+ in Stock

Art. no.: 1007381

Optionally available

Delivery information

Delivery time: 1–3 working days

Technical overview

38 °
50000 h
IP20
IK02

Leading and trailing edge phase dimmer: This product is dimmable using a trailing and leading edge phase dimmer.
Direct lighting - beam angle: This value describes the beam angle in degrees. The smaller the angle, the more concentrated the light will be.
Average lifespan in h: The average lifespan of a lightbulb or light source in hours.
IP protection rating: The IP protection class indicates the suitability of electrical equipment for different environmental conditions.
IK impact resistance rating: The IK impact resistance rating is a measure of the resistance of the housing of electrical equipment to mechanical stress, especially impact stress.

Technical data

Product name: NEW TRIA®
EAN Number: 4024163277860
Colour: black
Assembly: Recessed
Luminous Flux: 705 lm
Colour temperature: 2700 Kelvin
CRI: 90
Beam angle: 38 °
CCT switch: No
Height: 3.9 cm
Diameter: 5 cm
Material: Aluminium
IP Code: IP20
Shock resistance category: IK02
Shock resistance: 0.2 joule
Assembly details: Ceiling

electrical power: 8,3 W
Primary nominal voltage: 220-240V V ~ 50/60Hz
Secondary power / secondary voltage: 200 mA
Dimmable: Yes
Dimming technology: Leading edge, trailing edge
Inrush current level: 3 A
Inrush current duration: 30 µs
Number of lights on LS B16A: 88
Number of lights on LS C16A: 149
Weighted consumption: 9 kWh/1.000h
Service life: 50000 h
Energy efficiency class: LS_2874
Ambient temperature: 35 °C
Risk group: 1
Net weight: 0.147 kg
BIG WHITE Page: 79

Product information

Discover the new generation of our NEW TRIA® recessed ceiling light and configure an individual lighting experience. A modular element is the 7 W LED MODULE, which is available with different light colours (2700 K/3000 K) and beam angles (38°/60°) as a phase variant. The robust design and excellent colour reproduction index CRI >90 ensure exceptional quality. In addition, the NEW TRIA® LED MODULE impresses with its service life of L80B10@50,000h.

Downloads

Product information

Datasheet (PDF)

Manual (PDF)

Removal instructions (PDF)

Maßzeichnung (JPG)

Documents

CE declaration (PDF)

REACH (PDF)

Tender data

Tender Text (TXT)

GAEB file (D81)

Lighting planning data

Download Rolf Zip file (ZIP)
