GALEN 120

TOPSELLER

Width

Select the item now with matching

RRP£291.00Prices for business customers excl. VAT

25+ in Stock

Art. no.: 1003448

Delivery information

Delivery time: 1–3 working days

Technical overview

180 °
54000 h
IP65
IK03

Vertical pivot range: This product can be pivoted vertically.
Average lifespan in h: The average lifespan of a lightbulb or light source in hours.
IP protection rating: The IP protection class indicates the suitability of electrical equipment for different environmental conditions.
IK impact resistance rating: The IK impact resistance rating is a measure of the resistance of the housing of electrical equipment to mechanical stress, especially impact stress.
Compatible with through-wiring: Through-wiring is possible with this product.
CCT switch: By using the CCT switch integrated in this product, the light colour can be configured at installation to 3000K or 4000K.

Technical data

Product name: GALEN 120
EAN Number: 4024163236058
Colour: anthracite
Luminous Flux: 3000/3100 lm
Colour temperature: 3000/4000 Kelvin
CRI: 80
CCT switch: Yes
Width: 120 cm
Height: 6.2 cm
Material: Aluminium
IP Code: IP65
Shock resistance category: IK03
Shock resistance: 0.35 joule
Vertical tilting range: 180 °
electrical power: 34 W
Primary nominal voltage: 220-240V V ~ 50/60Hz

Secondary power / secondary voltage: 900 mA
Dali capable: No
Connection cable length: 11 cm
Inrush current level: 25 A
Inrush current duration: 500 µs
Number of lights on LS B16A: 10
Weighted consumption: 34 kWh/1.000h
Service life: 54000 h
Energy efficiency class: LS_2196
Ambient temperature: 45 °C
Risk group: 1
Net weight: 2.779 kg
BIG WHITE Page: 808

Product information

Thanks to the integrated mounting bracket and the splash-proof connection cables, the GALEN LED profile can be installed quickly and easily on walls, floors, or ceilings. It is most suitable as a form of lighting for displays and signs. Added to this is the practical CCT switch, which provides added flexibility as it allows the light colour to be adjusted between 3000 K (warm white) and 4000 K (neutral white) using an external switch. Robustly made and featuring high-performance LEDs, GALEN is perfect for creating effective or functional lighting in the outdoor areas of shops, hotels, restaurants, or in commercial buildings.

Downloads

Product information

Datasheet (PDF)

Manual (PDF)

Removal instructions (PDF)

Maßzeichnung (JPG)

Documents

CE declaration (PDF)

REACH (PDF)

Tender data

Tender Text (TXT)

GAEB file (D81)

Lighting planning data

Download ROLF file (ROLF)

Download ULD file (ULD)
