AKALO 83

RRP£35.00Prices for business customers excl. VAT

500+ in Stock

Art. no.: 1001264

Optionally available

Delivery information

Delivery time: 1–3 working days

Technical overview

90
30000 h
IK02
28

Leading and trailing edge phase dimmer: This product is dimmable using a trailing and leading edge phase dimmer.
Direct lighting - beam angle: This value describes the beam angle in degrees. The smaller the angle, the more concentrated the light will be.
Average lifespan in h: The average lifespan of a lightbulb or light source in hours.
IK impact resistance rating: The IK impact resistance rating is a measure of the resistance of the housing of electrical equipment to mechanical stress, especially impact stress.
UGR ≤: UGR= Unified Glare Rating. Indicates the standardised value of psychological glare. The smaller the value is, the lower the glare.
CCT switch: By using the CCT switch integrated in this product, the light colour can be configured at installation to 3000K or 4000K.

Technical data

Product name: AKALO D83
EAN Number: 4024163195683
Colour: white
Luminous Flux: 800/880/850 lm
Colour temperature: 3000/4000/5700 Kelvin
CRI: 80
Beam angle: 90 °
UGR ≤: 28
CCT switch: Yes
Different light outlets: 1
Height: 6.5 cm
Diameter: 11 cm
Material: Aluminium
Shock resistance category: IK02
Shock resistance: 0.2 joule
Installation diameter: 9.2 cm

Installation depth: 7 cm
Shape of cut-out: round
electrical power: 9 W
Primary nominal voltage: 220-240V V ~ 50/60Hz
Secondary power / secondary voltage: 120 mA
Dimmable: Yes
Dimming technology: Leading edge, trailing edge
Dali capable: No
Inrush current level: 5 A
Inrush current duration: 300 µs
Weighted consumption: 9 kWh/1.000h
Service life: 30000 h
Energy efficiency class: LS_2176
Ambient temperature: 40 °C
Net weight: 0.19 kg
BIG WHITE Page: 115

Product information

The AKALO luminaire is a recessed ceiling light for universal use indoors. The light temperature is switchable in all versions. The electrical connection is made directly to the 230V mains supply.

Downloads

Product information

Datasheet (PDF)

Manual (PDF)

Removal instructions (PDF)

Maßzeichnung (JPG)

Documents

CE declaration (PDF)

REACH (PDF)

Tender data

Tender Text (TXT)

GAEB file (D81)

Lighting planning data

Download ROLF file (ROLF)

Download ULD file (ULD)

FIND A DIMMER. GOOD COMBINATION.

Please note the minimum load of the dimmers used.

Niko 310-0190X
LK Fuga LED Dimmer 180 Touch
Busch Jäger (6523U)
Eltako EUD 61 NPN-UC
Legrand PRO21 LED Dimmer 775659
