This value describes the beam angle in degrees. The smaller the angle, the more concentrated the light will be.
50000 h
Average lifespan in h
The average lifespan of a lightbulb or light source in hours.
IP44
IP protection rating
The IP protection class indicates the suitability of electrical equipment for different environmental conditions.
Technical data
Product name
DORISA 30
EAN Number
4024163190695
Colour
chrome
Assembly
Surface
Luminous Flux
420 lm
Colour temperature
4000 Kelvin
CRI
90
Beam angle
110 °
CCT switch
No
Different light outlets
1
Length
30 cm
Width
12 cm
Height
4 cm
Shape
rectangular
Material
Aluminium
IP Code
IP44
Assembly details
Wall
electrical power
5,2 W
Primary nominal voltage
220-240V V ~ 50/60Hz
Secondary power / secondary voltage
120 mA
Dali capable
No
Inrush current level
7.44 A
Inrush current duration
121 µs
Number of lights on LS B16A
83
Number of lights on LS C16A
83
Weighted consumption
6 kWh/1.000h
Service life
50000 h
Energy efficiency class
LS_10350
Ambient temperature
40 °C
Risk group
0
Net weight
0.316 kg
BIG WHITE Page
339
Product information
The DORISA mirror luminaire is equipped with modern LED technology. The narrow head of the luminaire is mounted to the mirror or cabinet using an arm. The clamping range is between 3 and 6 mm, making individual lighting of your bathroom possible. Gentle lighting with heat radiation that is barely detectable due to having built-in LEDs. The luminaire is available in two housing colours. Because of the LED constant current driver, the electrical connection is made directly to a 230V mains power supply. The luminaire contains built-in LED lamps.
